• D520

D520

  • OrcaTorch D520 is a palm-sized diving light with a mechanically rotary switch. The rotary switch offers high reliability underwater. Using the USA CREE XM-L2(U4) neutral white LED, its max output can reach 1000 lumens, meanwhile the 5000K LED color temperature provides superb color rendition. Powered by one 18650 battery, its max runtime can reach 2 hours.

  • Featuring

    * Cree XM-L2(U4) LED, max 1000 lumens output
    * Uses 1*18650/2*CR123A/2*16340 battery
    * Mechanically head rotary switch offers high reliability underwater
    * Water pressure resistant construction ,depth rated to 150 meters
    * Reverse polarity protection, to protect from improper battery installation
    * Over-discharge protection function
    * Aircraft-grade high strength aluminum material
    * The latest diamond grade hard-anodized seawater-corrosion-resistance finish
    * Alloy aluminum reflector with professional optical analysis

Share to:
ANSI/NEMA FL1Mode
Output1000 Lumens
Runtime

2h

Beam Distance250m(On land)
Intensity14300cd
Impact Resistant1m
Waterproof Underwater 150m
Working Voltage3-8.4V
Dimension134.5mm(Length) x 24mm(Diameter) x 30mm(Head)
Net Weight113.5g(Excluding Battery)
Accessories

18650 battery, charger, O-ring, Lanyard


OrcaTorch D520 underwater test by Akmal Obit

2018-07-24

OrcaTorch D520 Scuba Diving Light reviewed by My Vegan Experiment

2018-07-18


TESTED - OrcaTorch D520 & D560 Review

2017-12-22

ORCATORCH D520 Scuba Diving Flashlight 1000 Lumen LED Light Review

2017-08-26
User Manual
D520 User Manual
OrcaTorch C105 charger is included in OrcaTorch D520 dive light kit and it could be used for charging battery type 26650, 18650, 16340, and 14500.
We printed the serial number on the head of the OrcaTorch D520 dive light, 8 number.
