• D570-GL

D570-GL

  • OrcaTorch D570 is a 1000 lumens dive light specially designed for recreational diving and commercial diving. Besides regular white beam, it offers quick access to the green laser light. The two light sources can be controlled independently which meet your different usage scenes.

  • Featuring

    * Two light sources :8°white beam + green laser light

    * Easy operation with side button switch,

    * Battery indicator

    * Intelligent Over-Heat protection

    * Water pressure resistant construction ,depth rated to 150 meters

    * Reverse polarity protection, to protect from improper battery installation

    * Over-discharge protection function

    * Aircraft-grade high strength aluminum material

    * The latest diamond grade hard-anodized seawater-corrosion-resistance finish

    * Two sides coated toughened glass with high water pressure resistance under deep water


Share to:

D570  2-in-1 Beam + Laser Dive Light

The ability to point and signal conveniently is now provided by the green (or optional red) laser. This is not only a scuba signalling device but a 1000 lumens dive light!

D570 2.jpg


Titanium Alloy Side Button Switch

The 8° White Beam and 1000m Green Laser can be controlled independently.


Battery Indicator

In dive light mode, the battery indicator shows the battery charge level.


Powered by One 18650 Li-ion Battery

The white light lasts around 1 hour 51mins. With the reverse polarity protection, it is protected from improper battery installation.


Water Pressure Resistant Construction

Aircraft-grade high strength aluminum material, two sides coated toughened glass with high water pressure resistance under deep water 150m


Net Weight:176g (excluding battery)


Applications

It can be used for scuba diving lighting, rescue signals, instructor pointer,identifing hard to see objects, attracting wildlife, spear gun sight, etc.


Safety Notice: Please avoid shining the light directly into the eyes and NEVER aim the laser pointers at aircraft.

ANSI/NEMA FL1WhiteLaser
Output

1000lumen

-
Runtime1h 51mins

13h36min (D570-GL)

80h (D570-RL)

Beam Distance281(on land)

>1000m (on land)

Intensity19800cd-
Impact Resistance1m
WaterproofUnderwater 150m
Working Voltage3-4.2V
Dimension

134mm(Length) x 26mm(Diameter) x 40mm(Head)

Net Weight176g(Excluding Battery)
AccessoriesOne 18650 Li-ion battery, Charger, Lanyard, O-rings

OrcaTorch D570 dive light review

2018-12-16

The Torch for Scuba Dive Instructors | OrcaTorch D570-GL | Unboxing

2018-12-18


Powerful Dive Torch with Laser | OrcaTorch D570 GL Review

2019-02-13

Orcatorch 570 GL testing at the Tilly Foster Mine

2019-05-27



User Manual
D570 User Manual

PDF
