D520

  • OrcaTorch D520 is a palm-sized diving light with a mechanically rotary switch. The rotary switch offers high reliability underwater. Using the USA CREE XM-L2(U4) neutral white LED, its max output can reach 1000 lumens, meanwhile the 5000K LED color temperature provides superb color rendition. Powered by one USB-C 18650 battery, its max runtime can reach 2 hours.

  • Featuring

    * Max 1000 lumens output
    * Uses 1*18650/2*CR123A/2*16340 battery
    * Mechanically head rotary switch offers high reliability underwater
    * Reverse polarity protection, to protect from improper battery installation
    * Over-discharge protection function

    * Intelligent over-heat and over-discharge protection function

    * Water pressure resistant construction, depth rated to 150 meters

    * Reverse polarity protection, to protect from improper battery installation

    * Constructed from high-strength A6061-T6 aluminum

    * Hard anodized finish for durability and corrosion resistance

    * Two sides coated toughened glass with high water pressure resistance

Share to:
OrcaTorch D520 small scuba dive light (1).jpg
OrcaTorch D520 small scuba dive light (2).jpg
OrcaTorch D520 small scuba dive light (3).jpg
OrcaTorch D520 small scuba dive light (4).jpg
OrcaTorch D520 small scuba dive light (5).jpg
OrcaTorch D520 small scuba dive light (6).jpg
OrcaTorch D520 small scuba dive light (7).jpg
OrcaTorch D520 small scuba dive light (8).jpg
OrcaTorch D520 small scuba dive light (9).jpg
OrcaTorch D520 small scuba dive light (11).jpg
OrcaTorch D520 small scuba dive light (12).jpg
OrcaTorch D520 small scuba dive light (13).jpg
OrcaTorch D520 small scuba dive light (14).jpg


ANSI/NEMA FL1Mode
Output1000 Lumens
Runtime

2h

Beam Distance250m(On land)
Intensity12000cd
Impact Resistant1m
Waterproof Underwater 150m
Working Voltage3-8.4V
Dimension134.5mm(Length) x 24mm(Diameter) x 30mm(Head)
Net Weight129g(Excluding Battery)
Accessories

1*18650 USB-C battery, 1* USB-C charging cable, 3* Spare-O-rings, 1* Lanyard



Notice:

Stated data has been measured according to the international flashlight test standards ANSI/NEMA FL1 using one 18650 Li-ion battery (3.7V, 3400mAh) under laboratory conditions. The parameters are approximate and may vary between flashlights, batteries, and environments.



OrcaTorch D520 underwater test by Akmal Obit

2018-07-24

OrcaTorch D520 Scuba Diving Light reviewed by My Vegan Experiment

2018-07-18


TESTED - OrcaTorch D520 & D560 Review

2017-12-22

ORCATORCH D520 Scuba Diving Flashlight 1000 Lumen LED Light Review

2017-08-26
User Manual
D520 User Manual
OrcaTorch C105 charger is included in OrcaTorch D520 dive light kit and it could be used for charging battery type 26650, 18650, 16340, and 14500.
We printed the serial number on the head of the OrcaTorch D520 dive light, 8 number.
Absolutely it can. Its beam angle is between 12 ~ 72 degree. 72 degree can view the surrounding environment, 12 degree concentrated beam can be long-range. Using 5000k neutral white LED, has strong underwater penetration. D520 would be qualified for both recreational diving as a primary light and deep diving as a backup light.
From the directions it appears you have to turn it on before entering the water and turn it off upon exiting the water.

ORDER YOUR D520

Please leave your contact information, our dealer nearby will contact you soon. You can find a dealer or buy it from OrcaTorch dive light online store.

*
*
*
*
